Cummins ISX15 Wire Diagram CM2350

$59.95

Factory printed Cummins wire diagram.  Sturdy, laminated all-weather construction.

Availability: 1 in stock

SKU: TMCU0638-SALE Categories: ,

Laminated fold-out factory printed Cummins ISX15 Wire Diagram for the engine control system for this Cummins engine. Includes specifications, & fault code info.  Wire diagram is color coded & shows both the Cummins responsibility & the OEM responsibility.  This diagram package is easy to use & will help technicians shorten their diagnostic time, allowing them to increase shop profits.

Engine:
ISX15 CM2350

Cummins ISX15 Wire Diagram CM2350
Cummins ISX15 Wire Diagram CM2350
Cummins ISX15 Wire Diagram Coverage Includes:
  • ECM pin locations
  • Wire diagram (color-coded)
  • Connectors
  • Each controlled or controlling sensor, etc
  • Cummins responsibility & truck manufacturer responsibility connections
  • Electrical specifications & reading parameters (volts-amps-ohm readings)
  • Fault codes, fault reasons, fault effects

Laminated surface allows for the use of erasable marker to make notes while performing diagnostics which can be erased when finished.

Looking for Cummins Insite? Click Here

Looking for more Cummins manuals? Click Here
